LOADER MODEL

3650 CL

Standard Bucket Size [in]

75

Maximum Lift Height [in]

111.5

Dig Depth [in]

4.5

Lift Capacity to Full Height at Pivot Pin [lbs]

2700

Breakout Force [lbs]

5100

Shipping Weight [lbs}

1450

ENGINE

Type

Four-stroke, Natually Aspirated, Direct Injection, Water Cooled Diesel Engine

Engine HP {kW} @ RPM

40 (29.9) @ 2800

Displacement [in³ (cc)]

166.7 (2732)

Number of Cylinders

4

Fuel Tank [gal (L)]

11.3 (42.8)

DRIVE TRAIN

Transmission

HST - 3 Ranges

Number of Speeds

Infinite

Clutch

Wet

Brakes

Oil Immersed Wet Disc Brake

PTO

Type

Independent

Rear PTO RPM

540 @ 20

Mid PTO RPM

N/A

PTO HP (kW)

30.5 (22.7)

HYDRAULICS

Type

Open Center

Implement Pump Output [gpm (L/min)]

11 (41.6)

Maximum Total Flow [gpm (L/min)]

16 (60.6)

3-Point Hitch

CAT I & II w/Telescoping Stabilizers & Flex Lines

Lift Capacity [lb (kg)]

3090 (1401)

ELECTRICAL

Battery

12 V, 925 CCA

Alternator

12 V, 45 A

DIMENSIONS

Overall Length [in (mm)]

129 (3276)

Overall Width [in (mm)]

73.7 (1871)

Overall Height [in (mm)]

98.7 (2506)

Wheelbase [in (mm)]

75 (1905)

Minimum Ground Clearance [in (mm)]

13.6 (345)

Turning Radius [ft (m)]

10.3 (3.1)

Weight [lb (kg)]

4367 (1980)

WHEELS & TIRES

AG [Front/Rear]

9.5-16 / 14.9-24

IND [Front/Rear]

12 x 16.5 / 16.9 x 24

TURF [Front/Rear]

29 x 12.5 - 15 / 44 x 18 - 20
